Alu alu blister foil specification

July 1, 2019

Alu alu blister foil specification supplied by Haomei can meet the requirements of alu alu blister packaging. The alloy grades used in medicinal aluminum blister foil are generally 8011, 8021, 1235, generally O temper, which is soft, only 8011 aluminium foil has H18 temper. The thickness of alu alu blister foil is only tens of microns, the finished product width is generally in above 300mm, the inner diameter of the core is 76mm, the maximum outer diameter can reach 500mm, and the thickness tolerance is no more than 5%. The result is A grade by brushing water test.

alu alu blister foil specification

Pharmaceutical aluminum blister foil is mainly used for packaging medicines to protect medicines and improve the stability and reliability of medicines. Blister packaging has become the most important way of packaging medicine tablets and capsules. It is estimated that alu alu blister foil packaging materials will account for 60% to 70% of the packaging of tablets and capsules in the future, which is one of the most promising drug packaging forms at present. The pharmaceutical alu alu blister foil specification are:

Alloy Status Thickness Width Core Inner Diameter (mm) Maximum Outer Diameter (mm Thickness Tolerance (%) Brush Water Test
8011 aluminum foil H18 0.018-0.025mm 300mm or more 76 500 ≦5 A grade
8011 aluminum foil O 0.04-0.045mm 300mm or more 76 500 ≦5 A grade
8021 aluminum foil O 0.047-0.065mm 300mm or more 76 500 ≦5 A grade
1235 aluminum foil O 0.006-0.009mm 300mm or more 76 500 ≦5 A grade
